SPECIFICATIONS | |
Magnification With Lens | 25-50x |
Exit pupil diameter (mm) | 3.2-1.6 |
Field of view (ft/1000 yds / m/1000 m) | 126-81 ft / 42-27 m |
Field of view (degrees) | 2.4-1.55 |
Field of view for spectacle wearers (degrees) | 2.4-1.55 |
Field of view. apparent (degrees) | 60-70 |
Weight without battery (oz / g) | 71.6 / 2030 |
Length (in / mm) | 15.9 / 403 |
|
|
Magnification With Lens | 20-60x |
Exit pupil diameter (mm) | 4.0-1.3 |
Field of view (ft/1000 yds / m/1000 m) | 108-60 / 36-20 |
Field of view (degrees) | 2.1-1.1 |
F.O.V for spectacle wearers (degrees) | 2.1-1.1 |
Field of view. apparent (degrees) | 40-65 |
Weight without battery (oz / g) | 70.4 / 1995 |
Length straight view (in / mm) | 15.9 / 403 |
|
|
|
|
Effective objective lens diameter (mm) | 80 |
Shortest focusing distance (ft / m) | 19 / 6 |
Diopter correction at 8 (dpt) | > 5 |
Diopter correction reticle | +/- 5 dpt |
Objective filter thread | M 82 x 0.75 |
Functional temperature | -40 C to +55 C |
Storage temperature | -40 C to +70 C |
Submersion tightness | 13 ft (4m) water Depth |
|
|
