SPECIFICATIONS
|
|
Magnification
|
20-60x
|
Exit pupil diameter (mm)
|
3.3-1.1
|
Field of view (ft/1000 yds / m/1000 m)
|
108-60 /
36-20
|
Field of view (degrees)
|
2.1-1.1
|
FoV for spectacle wearers (degrees)
|
2.1-1.1
|
Field of view. apparent (degrees)
|
40-65
|
Light transmission (%) total product
|
86
|
Weight angled view (oz / g)
|
48.3 / 1370
|
Length angled view (in / mm)
|
14.6 / 370
|
Focal length with TLS APO (mm)
|
600-1800
|
|
|
Effective objective lens diameter (mm)
|
65
|
Eye relief (mm)
|
17
|
Shortest focusing distance (ft / m)
|
9.8 / 3
|
Diopter correction at 8 (dpt)
|
> 5
|
Objective filter thread
|
M 67 x 0.75
|
Functional temperature
|
-25 C to +55 C
|
Storage temperature
|
-30 C to +70 C
|
Submersion tightness
|
13 ft (4m)
water depth
|
|
|
